Linear cage
Linear cages are essential components for precision guidance systems within industrial machinery. These devices ensure the optimal retention and positioning of rolling elements, thereby guaranteeing smooth linear motion and excellent mechanical stability during movement. Their design enables guidance solutions to be efficiently integrated into restricted spaces whilst ensuring a balanced distribution of the loads applied to translation systems.
Affichage 1–9 sur 9 références
INA LINEAIRE
FF2025-ZW-B-0-2
INA LINEAIRE Guidages par cages
Sur devisRéponse sous 24 h ouvrées
INA LINEAIRE
FF2515/0-2
INA LINEAIRE Guidages par cages
Sur devisRéponse sous 24 h ouvrées
INA LINEAIRE
FF2535-ZW-0-2
INA LINEAIRE Guidages par cages
Sur devisRéponse sous 24 h ouvrées
INA LINEAIRE
FF3020/0-2
INA LINEAIRE Guidages par cages
Sur devisRéponse sous 24 h ouvrées
INA LINEAIRE
FF3045-ZW-0-2
INA LINEAIRE Guidages par cages
Sur devisRéponse sous 24 h ouvrées
INA LINEAIRE
FF3525/0-2
INA LINEAIRE Guidages par cages
Sur devisRéponse sous 24 h ouvrées
INA LINEAIRE
FF3555-ZW-0-2
INA LINEAIRE Guidages par cages
Sur devisRéponse sous 24 h ouvrées
INA LINEAIRE
FFW3045
INA LINEAIRE Guidages par cages
Sur devisRéponse sous 24 h ouvrées
About Linear Cages
In the field of linear guidance, the linear cage is a structural element that differs from bushings, ball bushings or profiled rail guides through its support function for rolling bodies. This component is frequently associated with shafts and bearings to form complete translation systems. The INA LINEAIRE brand offers solutions adapted to various mechanical configurations, requiring rigorous selection based on the nature of the loads, the dimensions required and the constraints of the working environment. For applications demanding high motion precision, it is crucial to consider the compatibility between the cage and the shaft, as well as the mounting requirements.
The choice of guidance equipment also depends on the type of installation, whether it involves electric axes, fixing accessories or shaft flanges. Selection criteria include static and dynamic load capacity, the expected guidance precision, as well as resistance to specific operating conditions. Although certain technologies, such as linear rolling guides on profiled rails, are governed by the ISO 12090 standard, the use of linear cages forms part of a complementary approach to machine kinematics. Proper installation ensures the longevity of linear motion and limits the risk of premature wear of adjacent components.
Frequently asked questions — Linear Cages
What is the fundamental difference between a linear cage and a ball bushing?
The linear cage acts as a structural element specifically dedicated to supporting rolling bodies, unlike the ball bushing which constitutes a more integrated guidance unit. This component is designed to be combined with shafts and bearings to form complete translation systems adapted to the specific requirements of the machine. The choice between these two technologies will depend on the mechanical architecture selected and the configuration of the guidance components needed to ensure the desired linear motion.How should a linear cage be correctly selected for a high-precision application?
For applications demanding high motion precision, selection must be based on a rigorous analysis of foreseeable static and dynamic loads. It is imperative to carefully assess the dimensional compatibility between the cage and the shaft, whilst complying with the strict mounting requirements related to the working environment. An appropriate selection, taking into account the type of installation and operating constraints, ensures the longevity of linear motion and prevents premature wear of components adjacent to the guidance system.Are linear cages subject to the ISO 12090 standard?
No, the ISO 12090 standard applies specifically to linear rolling guides on profiled rails, and not to linear cages. The use of linear cages forms part of a complementary approach to machine kinematics, distinct from that of profiled rails. Although this standard governs certain guidance technologies, it does not directly concern the design or use of linear cages as structural support elements for rolling bodies.Which technical criteria should be prioritised to ensure the longevity of linear guidance?
The longevity of the guidance relies on a rigorous selection that incorporates the nature of the loads, the dimensions required and the specific conditions of the working environment. It is necessary to analyse the expected static and dynamic load capacity as well as the guidance precision essential to the machine's kinematics. An appropriate installation, which takes into account compatibility with shafts, bearings, fixing accessories or shaft flanges, is essential to limit the risk of premature wear and ensure reliable translation over the long term.
